衛生級卡箍式止回閥詳細介紹
衛生級卡箍式止回閥結構尺寸：
| 卡箍式止回閥/3A |
|
Size |
B2 |
D |
A |
| 1/2" |
87.0 |
25.4 |
102.0 |
| 3/4" |
87.0 |
25.4 |
102.0 |
| 1" |
87.0 |
50.5 |
102.0 |
| 1 1/2" |
87.0 |
50.5 |
102.0 |
| 2" |
100.0 |
54 |
113.4 |
| 2 1/2" |
115.0 |
77.5 |
122.0 |
| 3" |
128.0 |
91.0 |
142.0 |
| 4" |
164.0 |
119.0 |
182.0 |
| 卡箍式止回閥/DIN |
|
Size |
B2 |
D |
A |
| DN15 |
87.0 |
34.0 |
102.0 |
| DN20 |
87.0 |
34.0 |
102.0 |
| DN25 |
87.0 |
50.5 |
102.0 |
| DN32 |
87.0 |
50.5 |
102.0 |
| DN40 |
87.0 |
50.5 |
102.0 |
| DN50 |
100.0 |
64.0 |
113.4 |
| DN65 |
115.0 |
91.0 |
122.0 |
| DN80 |
128.0 |
106.0 |
142.0 |
| DN100 |
164.0 |
119.0 |
182.0 |
| 卡箍式止回閥ISO/IDF |
|
Size |
B2 |
D |
A |
| φ25 |
87.0 |
50.5 |
102.0 |
| φ38 |
87.0 |
50.5 |
102.0 |
| φ51 |
100.0 |
64.0 |
113.4 |
| φ63 |
115.0 |
77.5 |
122.0 |
| φ70 |
128.0 |
91.0 |
142.0 |
| φ100 |
164.0 |
119.0 |
182.0 |
| 卡箍式止回閥/SMS |
|
Size |
B2 |
D |
A |
| 25 |
87.0 |
50.5 |
102.0 |
| 32 |
87.0 |
50.5 |
102.0 |
| 38 |
87.0 |
50.5 |
102.0 |
| 51 |
100.0 |
64.0 |
113.4 |
| 63 |
115.0 |
77.5 |
122.0 |
| 76 |
128.0 |
91.0 |
142.0 |
| 89 |
128.0 |
106.0 |
142.0 |
| 102 |
164.0 |
119.0 |
182.0 |
提示：本文中所有文字、數據、圖片均只適用于參考，需要了解更詳細的【衛生級卡箍式止回閥】參數、選型、價格等請聯系我們，我們將竭誠為您服務！
